Description

The Williams WBCF40-SS blast chiller/freezer is a premium-grade piece of catering refrigeration equipment designed for professional kitchens, hotels, restaurants, catering operations and other food service environments. Built with a 40 kg capacity, robust stainless-steel finish, and advanced chilling/freezing technologies, it gives operators full control of the temperature reduction process from hot cooked food through to safe chilled or frozen storage.

With this model, the hazards of slow cooling are eliminated, food safety risks are mitigated, and quality — texture, taste and appearance — is preserved. On top of that, the unit is designed to integrate seamlessly into a commercial kitchen environment, offering simplicity of use, good reliability and an aesthetic finish appropriate for high-visibility areas.

Size, Construction & Technical Data

• External Dimensions: Height 1720 mm × Width 707 mm × Depth 805 mm

• Insulation Thickness: 75 mm

• Material Finish: Stainless steel (interior and exterior)

• Colour: Silver

• Weight: Approx. 164 kg

• Refrigerant: R290 (natural hydrocarbon)

• Voltage: 240 V

• Capacity: 40 kg of food per cycle (chill or freeze)

Ideal Applications

The Williams WBCF40-SS is ideal for:

• Medium to large kitchens preparing multiple batches of food that need rapid cooling or freezing.

• Hotels, banqueting venues, and event caterers producing food in advance for later service.

• Restaurants seeking consistent food safety and quality across multiple service periods.

• Healthcare and education catering environments using cook-chill or cook-freeze systems.

• High-temperature kitchen environments requiring reliable chilling performance in ambient conditions up to 43 °C.

Installation & Operational Considerations

Placement:
Ensure sufficient clearance around the unit for ventilation and optimum airflow performance.

Power:
Requires a 240 V electrical supply with appropriate protection and connection according to site wiring regulations.

Condensate & drainage:
Includes an automatic vapourising condensate system — ensure local installation allows safe vapour discharge or drainage where applicable.

Mobility & positioning:
The robust castors allow the unit to be moved for cleaning or repositioning. Always lock the brakes once the chiller/freezer is in place.

Loading:
For the best results, load the cabinet evenly using suitable trays or containers. Avoid overloading and ensure adequate air circulation.

Cycle selection:
Choose from hard chill, soft chill, hard freeze, soft freeze, store or core probe modes depending on product density and moisture level.

Maintenance:
Regularly clean the stainless-steel surfaces, check door seals for integrity, and schedule professional servicing in line with Williams’ recommendations to maintain optimal performance and warranty coverage.

Operating environment:
Although capable of functioning efficiently up to 43 °C ambient, maintaining good ventilation in the kitchen will maximise efficiency and reduce compressor strain.

Proven reliability:
Williams Refrigeration has a long-standing reputation for high-quality, durable, and energy-efficient refrigeration solutions trusted throughout the hospitality industry.

Powerful performance:
Capable of chilling from +90 °C to +3 °C in 90 minutes or freezing to –18 °C in 240 minutes, this model provides powerful, dependable cooling capacity for demanding kitchen environments.

Sustainability built-in:
The use of R290 refrigerant and high-density insulation ensures compliance with current environmental regulations and energy efficiency standards.

Operator-friendly design:
Simple controls and automated operation reduce the learning curve for staff and allow seamless integration into busy workflows.

Compact yet capacious:
Its streamlined size and full 40 kg load capacity make it ideal for kitchens with limited floor space that still require high-volume throughput.

Enhanced workflow efficiency:
By pre-preparing and chilling batches, chefs can improve service consistency, reduce waste, and maintain strict hygiene standards without compromising food quality.

Professional presentation:
The sleek stainless-steel finish not only provides durability but also complements modern professional kitchen aesthetics.

The Williams WBCF40-SS Reach-In Blast Chiller/Freezer is an advanced, professional-grade refrigeration solution designed to meet the rigorous demands of modern catering and hospitality operations. With its impressive 40 kg capacity, rapid chill and freeze cycles, and intelligent airflow design, it ensures maximum food safety and superior product quality every time.

Its energy-efficient performance, eco-friendly refrigerant, and robust stainless-steel construction make it a reliable investment for any commercial kitchen. Easy to operate and simple to maintain, it helps streamline kitchen processes while supporting HACCP compliance and environmental responsibility.

Whether you’re a busy restaurant, hotel, event caterer, or institutional kitchen, the WBCF40-SS delivers the speed, safety, and consistency you need to keep your food operations running smoothly — without compromising quality or taste.
