Designline Drop In Slimline Multideck Assisted Service 900mm
Designline Drop In Slimline Multideck Assisted Service 900mm - Display Fridges & Freezers
3 Shelves. Assisted Service. 900mm Wide. Rear Door
Original price was: £7,069.99.£5,949.39Current price is: £5,949.39. Ex. VAT
Description
Offer your customers a visual feast of your finest chilled produce with this assisted service Designline Drop In Cold Patisserie. Illuminated through an overhead gantry, the three adjustable shelves and cold deck area offer plenty of space to arrange your foods and drinks displays to push quick buys in high output establishments. Employing hydrocarbon refrigerant that cuts environmental waste and running costs, the deck plates inside can be removed and the front glass tilted for easy cleaning, and an internal evaporator cuts the need for site drainage. Operating around the clock, this drop in display is ideal for businesses working at all times of the day.
Please note: special-to-order. This product is non-returnable.
- Elliptical curved gantry in polished steel & aluminium, in a toughened glass front screen and side panels. Black powder coated steel base unit. (Fascia panel optional)
- Each chilled shelf features diffused lighting, product stop and 40mm tall ‘point of sale’ display/ticket strip
- Gantry is fitted with toughened glass full height front screen and side glass protection to the customer side of the display
- Additional product illumination from diffused lighting within the curved profile gantry
- Curved glass profile is designed to complement other units within the Designline range
- Features eye level gantry mounted digital temperature display and control panel (to customer side of display)
- Special-to-order. Non-returnable
- Drinks display examples: bottled, canned or carton drinks, water, lemonade, fruit juice. Food display examples : Pies, pasties, sausage rolls, sandwich fillings, cheese
- Features 3 chilled toughened glass display shelves with adjustable height and angle
- The 900mm long deck display area & shelves are chilled by energy efficient hydrocarbon refrigerant (r290)
- Freestanding for assisted service application. (1 hinged rear door to display)
Additional information
| Brand | Designline |
|---|---|
| Dimensions | 1467(H) x 900(W) x 750(D)mm |
| Is A Plug Fitted? | Yes |
| Voltage | 230V |
| Manufacturers Warranty | 1 Year |
| Main Colour | Silver |
| Secondary Colour | Silver |
| Main Category | Display Refrigeration |
| Product Family | Refrigeration |
| Product Depth | 750 |
| Door Location | Back |
| Power | Plug |
| Number Of Seats | 3 |
| Mobility | Feet |
| Width (mm) | 900 |
| Product Cooling Type | Fan Assist |
| Number Of Fridge Doors | 1 |
| Delivery To Ireland | 8-10 weeks |
| Temperature Range | -1°C to 5°C |
| Operating Temperature Range | -1 °C to 5 °C |
| Product Type | Multidecks |
| Sub Category | Multideck Displays |
| Section | All Multidecks |
| Light Type | LED |
| Blade Material External | Stainless Steel |
| Finish Type | Stainless Steel |
| Fridge Finish | Stainless Steel |
| Cooling Type | Refrigerator |
| Product Weight | 190kg |
| Feat Type | Lockable Castors |
| Wattage | 1.5 |
| Noise Level (dB) | 63.8 |
| Height (mm) | 1467 |
| Capacity | 228.6Ltr |
| Internal Dimensions | 707(H) x 870(W) x 610(D)mm |
| Power Type | 1.5kW, 230V, 13A |
| Refrigerant Type | R290 / GWP 3 / 345g |
| Capacity (ml) | 228.6 |
| Supplier Reference | PC9ASHT |
| Weight | 190 kg |
Frequently Asked Questions
CED Designline Drop In Slimline Multideck Assisted Service 900mm FAQs
What is the CED Designline Drop In Slimline Multideck Assisted Service 900mm best suited to?
The CED Designline Drop In Slimline Multideck Assisted Service 900mm is designed for commercial kitchens that need organised, dependable temperature-controlled storage close to the workflow.
What capacity does the CED Designline Drop In Slimline Multideck Assisted Service 900mm provide?
The CED Designline Drop In Slimline Multideck Assisted Service 900mm has a capacity of 228.6Ltr. Assess this alongside shelf layout, door format and expected stock rotation.
What temperature range does the CED Designline Drop In Slimline Multideck Assisted Service 900mm operate at?
The operating temperature range is -1°C to 5°C. Keep airflow paths clear, avoid overloading and monitor the displayed temperature as part of normal food-safety checks.
How does the CED Designline Drop In Slimline Multideck Assisted Service 900mm control and maintain temperature?
The CED Designline Drop In Slimline Multideck Assisted Service 900mm provides these operating features:
- Gantry is fitted with toughened glass full height front screen and side glass protection to the customer side of the display
- Features eye level gantry mounted digital temperature display and control panel (to customer side of display)
- Drinks display examples: bottled, canned or carton drinks, water, lemonade, fruit juice. Food display examples : Pies, pasties, sausage rolls, sandwich fillings, cheese
- Freestanding for assisted service application. (1 hinged rear door to display)
How is stock arranged inside the CED Designline Drop In Slimline Multideck Assisted Service 900mm?
The internal arrangement includes 3 shelves and 1 door. Freestanding for assisted service application. (1 hinged rear door to display). Arrange stock so that cold air can circulate and frequently used items remain easy to reach.
What cooling system and refrigerant does the CED Designline Drop In Slimline Multideck Assisted Service 900mm use?
The cooling system is Fan Assist. It uses R290 / GWP 3 / 345g refrigerant. Correct ventilation, clean air paths and routine condenser care are important for stable performance and efficient operation.
What are the dimensions and net weight of the CED Designline Drop In Slimline Multideck Assisted Service 900mm?
The CED Designline Drop In Slimline Multideck Assisted Service 900mm measures 1467(H) x 900(W) x 750(D)mm and has a net product weight of 190kg. Check the delivery route, final position and required operating clearances before ordering.
What power supply does the CED Designline Drop In Slimline Multideck Assisted Service 900mm require?
The CED Designline Drop In Slimline Multideck Assisted Service 900mm requires an electrical supply rated at 1.5kW, 230V, 13A. A plug is fitted.
How should the CED Designline Drop In Slimline Multideck Assisted Service 900mm be cleaned and maintained?
Clean the CED Designline Drop In Slimline Multideck Assisted Service 900mm interior, shelves and door seals regularly with suitable non-abrasive products. Keep ventilation openings and condenser areas clear, avoid blocking the internal airflow and follow the model-specific defrost and maintenance instructions.
How can I identify the correct CED Designline Drop In Slimline Multideck Assisted Service 900mm model for ordering and support?
Quote Smart Hospitality Supplies product code CW661 when ordering or requesting support. The model reference is PC9ASHT. It includes a one-year warranty.
